KATEGORIJA

• Media mikser / player

DIMENZIJE

š: x v: x d: x m: kg

TAGOVI

ecler

SPECIFIKACIJE

• 4 MIC / ST LINE inputs
• 1 ST LINE input
• 1 MIC input
• 1 ST output o 2 x mono output (A and B outputs)
• 1 mono output (C output)
• Independent inputs routing for zones A, B, C
• 1 AUX/REC output
• Independent 3-band EQ control for outputs A/B and output C
• MUTE port triggered by external contact closure
• Switchable talkover function, from IN1 to IN5 over A, B, C outputs

• Number of input ports

  4, MIC/LINE
  1, MIC
  1, LINE ST

  Connection type

  MIC: 3-pin Euroblock
  LINE: RCA

  Input sensitivity

  IN 2-5 LINE: 0dB
  IN 6 LINE: 0(-6)dB internally selectable
  IN 1-5 MIC/BAL: -35 dB

  Input impedance

  IN 2-5 LINE: 50kΩ
  IN 6 LINE: 50kΩ
  IN 1-5 MIC/BAL: >1kΩ

  THD + Noise

  LINE <0.005%
  MIC BAL <0.04%

  CMRR

  MIC >60dB @ 1 kHz

  Phantom power

  +18VDC

• Power supply

  Universal external power supply (multi-plug)

  AC mains requirement

  100-240 VAC + External PSU 17.5VDC

  AC mains connector

  IEC mains inlet connector

  Power consumption

  18 VA
