SPECIFIKACIJE

• 6,5" subwoofer + 6,5" passive radiator
• Ready for 70/100V installations: power selector 60/120W & 8 Ω
• Euroblock connector and spring-loaded input terminals
• LPF cut-off frequency selection: OFF/ 120Hz / 150Hz
• U Wall-mount hardware included
• Available in black (RAL 9005) and white (RAL9003) colour
• EASE files available

• Effective Freq. Range

  50 Hz–1,5 kHz (-10dB)

  Power handling

  120 W RMS / 480 W Peak

  Sensitivity

  86 dB (1W/1m)

  Maximum SPL

  107 dB RMS / 113 dB peak

  Power options (Hi Z Multi-tap)

  70V/100V line transformer: 120W / 60W / 8Ω

  Recommended amplifier power

  250 W RMS

• Connection type

  Euroblock + spring loaded input terminals

  Power type selector

  TBC

  Installation options

  Surface, wall, desktop

  Environmental

  IP31

  Enclosure material

  MDF

  Grille material

  Steel

  Grille fixing system

  Screw fixation

  Flying points

  2 x M8

  Operating temperature

  Min: -10°C ; 14°F
  Max: 40°C ; 104°F

  Operating humidity

  <85% HR

  Storage temperature

  Min: -10°C ; 14°F
  Max: 40°C ; 104°F

  Storage humidity

  <90% HR

  Included accessories

  U Bracket / 5mm Allen Key / 6mm Allen Key


  Finished colour

  White (RAL 9003) or Black (RAL 9005)

  Dimensions

  390 x 250 x 130 mm / 15.35 x 9.84 x 5.12 in. (WxHxD)

  Weight

  8.2 kg / 18.07 lb

  Pieces per box

  1 piece

  Shipping dimensions

  535 x 535 x 470 mm / 21.06 x 21.06 x 18.50 in. (WxHxD)

  Shipping weight

  10.2 kg / 22.48 lb
