SPECIFIKACIJE

• External, universal Power Supply (100-240VAC 50-60Hz)
• Compatible with WiSpeak grip app for set up and control functions (available for Android and iOS), using Bluetooth® connection
• 3 audio inputs available:
• o Analogue stereo, unbalanced. 2 x RCA connectors
• o Analogue stereo, balanced. 2 x Euroblock 3p connectors
• o Bluetooth®, class 1 (up to 25 meters range, maximum)
• 1 x WiSpeak wireless audio signal transmitted (a mono conversion of the selected input)
• 1 x AUX OUT analogue signal available (a copy of the transmitted WiSpeak signal). It can be used for linking the unit to external audio devices, like amplifiers, mixers or subwoofer units
• MUTE port, to allow the system’s audio silencing when an external dry contact is closed
• REMOTE port, to allow a simple general volume control for the end user -within a programmable range- using a WPaVOL or compatible wall panel
• Maximum number of receivers under control per transmitter device = 24 units. The system can be extended by linking a new transmitter to an existing receiver, creating a second WiSpeak network that shares the audio contents and Master volume with the first (main) one
• Front panel controls for source (input) selection and general (Master) volume control
• Recommended maximum range from a CORE transmitter to any WiSpeak paired receiver (TUBE CUBE or GLOBE): 12 meters, with direct line of sight
• Front panel PAIR key: it allows pairing the receivers to the transmitter quickly and easily, for a basic set up of the WiSpeak system
• Front panel LED indicators
• Service USB-C port (not for external power supply, only for service updates & firmware)
