KATEGORIJA

• Ozvučenje
• Procesori
• Media mikser / player

DIMENZIJE

š: x v: x d: x m: kg

TAGOVI

ecler

Matrix

SPECIFIKACIJE

• 8x8 digital matrix (not expandable)
• Fully programmable and controllable via EclerNet software
• UCP (User Control Panels) remote control system, compatible with WPNETTOUCH and third-partydevices, such as computers, tablets, smartphones, etc.
• TP-NET protocol compatible, for third-party control systems integration
• DSP processing: signal generator, delays, full parametric EQ filters at inputs and outputs,inputs noise gate, level, mute, phase, vu-meters, outputs compressor / limiter, paging and ducking(priority & overriding), virtual and physical paging stations management, presets save &recovery, scheduled events triggering, etc.
• FREQUENCY SHIFTER function to avoid acoustic feedback, available in 4 inputs
• WPNET4KV and WPNET8K compatible control panels (using specific retro-compatible Firmware).

• Sampling rate

  48kHz

  Resolution

  24bit AKM

  Latency

  <2.9ms


  Frequency response

  5Hz to 24kHz (-3dB)

  Dynamic range

  AD:110dB, DA: 115dB

• Number of input ports

  8, Mic/Line

  Connection type

  Terminal block (symmetrical)

  Input sensitivity

  -50dBV to +10dBV in 0.5dB step

  Input impedanc

  Balanced, >4kΩ

  Max input level

  +27dBV = +30dBu

  THD + Noise

  THD+Noise @ 1kHz, 0dBV input (line) <0.004%
  THD+Noise @ 1kHz, -40dBV input (mic.) <0.008%

  CMRR

  65dB typ.

  Phantom power

  +42VDC, 5mA max. software switched
