SPECIFIKACIJE

• 18” powered subwoofer with a compact design
• 2400W built-in Class D amplification power
• Low frequency amplifier: 1200W
• Speaker output amplifier: 2x600W @ 4Ω
• Frequency range (-10dB): 38Hz – 250Hz
• Max. SPL @ 1m: 132 dB
• 2 x input connectors: XLR3 balanced
• 2 x XLR stack output connectors: XLR3 balanced
• 2 x powered output connectors: Speakon®
• 18 factory presets
• User control interface with LCD
• Black finish available

• Effective Freq. Range

  38 Hz - 250 Hz (-10dB)

  Maximum SPL

  132 dB

• Connection type

  2 x XLR, 2 x XLR3, 2 x Speakon®

  Installation options

  Fixed installations and portable applications

  Environmental

  IP20 rated

  Enclosure material

  15mm premium birch plywood with polyurea coating

  Mounting system

  Several mounting options

  Operating temperature

  Min: 0°C ; 32°F
  Max: 35°C ; 95°F

  Operating humidity

  <85% HR

  Storage temperature

  Min: -10°C ; 14°F
  Max: 50°C ; 122°F

  Storage humidity

  <90% HR

  Included accessories

  powerCON TRUE1 TOP connectors (NAC3FX-W-TOP & NAC3MX-WTOP), 250cm AC cable (EU plug) and 120cm Speakon

  Optional accessories

  LABI1-SAC, LABI1-SWK, LABI1-SPC

  Finished colour

  Black (RAL 9005)

  Dimensions

  513 x 513 x 704 mm / 20.2 x 20.2 x 27.7 in. (WxHxD)

  Weight

  39.1 kg / 86.2 lb

  Pieces per box

  Unit

  Shipping dimensions

  540 x 550 x 740 mm / 21.26 x 21.65 x 29.13 in. (WxHxD)

  Shipping weight

  42.7 kg /
