Name: ECLER - VIC8 - stropni zvučnik
Brand: ECLER

ECLER

ECLER - VIC8 - stropni zvučnik

ŠIFRA PROIZVODA: CVIC8

Stropni zvučnik s izvrsnim zvučnim performansama.

Serija VIC pruža izvrsnu kvalitetu zvuka zahvaljujući svojoj filozofiji beskonačnog odbijanja i visokofrekventnom pretvaraču vrhunskih performansi.

166.25 €

Fiksni tečaj konverzije: 1 € = 7,53450 kn

Za sve naše veleprodajne kupce unutar Zagrebačke županije vršimo BESPLATNU DOSTAVU na Vaš kućni prag !!!

iznad 66,36 € (500 Kn) dostava je besplatna na području CIJELE HRVATSKE!

KATEGORIJA

Ozvučenje
Zvučne Kutije
Instalacijski zvučnici

DIMENZIJE

š: x v: x d: x m: kg

TAGOVI

Zvučnici

Ugradbeni Zvučnici

ecler

SPECIFIKACIJE

2-way false ceiling loudspeaker
8” polypropylene woofe
0,5” steerable tweeter
Output 60WRMS @ 8 ohm
100V/70V in-line connection: 60 / 30 / 15 / 7,5 / 3,75W
Sensitivity (1W/1m): 90 dB SPL
Dimensions (ØxD): 232x115mm
Available in white (RAL9010) finish
Weight: 2.3kg
Effective Freq. Range
59 Hz-20 kHz (-10dB)
Coverage angle / Dispersion
120° conical
Power handling
60 W RMS / 240 W Peak
Sensitivity
90 dB (1W/1m)
Maximum SPL
108 dB continuous / 114 dB peak
Power options (Hi Z Multi-tap)
100: 60W / 30W / 15W / 7,5W / 8Ω
70: 60W / 30W / 15W / 7,5W / 3,75W / 8Ω
Recommended amplifier power
120 W RMS

Installation options

Ceiling

Grille material

Paintable aluminium

Operating temperature

Min: -10°C ; 14°F
Max: 40°C ; 104°F

Operating humidity

<85% HR

Storage temperature

Min: -10°C ; 14°F
Max: 40°C ; 104°F

Storage humidity

<90% HR

External diameter

282 mm / 11.10"

Internal diameter

245 mm / 9.64"

Recommended cut out diameter

246 mm/ 9.69"

Required depth

120 mm / 4.72"

Ceiling thickness

10mm / 0.39" min
50mm / 1.97" max

Finished colour

White (RAL 9010)

Dimensions

282 x 115 mm / 11.1 x 4.5 in.(ØxD)

Weight

2.3 kg / 5.07 lb

Pieces per box

Pair

Shipping dimensions

305 x 280 x 305 mm / 12 x 11.02 x 12 in. (WxHxD)

Shipping weight

5.5 kg / 12.13 lb
