Powersoft
ŠIFRA PROIZVODA: PF000691
Serija UnicaTM je
kompaktna, 1RU platforma pojačala
razvijen prvenstveno za instalirane
Aplikacija. 4-kanalni
verzija uključuje 5kW, 9kW, 12kW,
i modeli ukupne snage od 16 kW,
što UnicaTM čini jednim od najznačajnijih
dostupna rješenja s gustom snagom.
Izlazni kanali mogu voziti
Lo-Z i 70/100V vodovi bez problema,
isporučuje do 5200 W @ 4 Ω
za model od 16 kW, kada
asimetrično opterećen. Snaga
Opskrba omogućuje rad diljem svijeta
(100-240VAC), a opremljen je
s najnovijom generacijom jednostupanjske korekcije faktora snage
(PFC). The proprietary Smart Rails (SRM) omogućuje
opskrbnim railovima za prilagodbu u stvarnom vremenu
na potreban izlazni napon do
povećanja učinkovitost i smanjenja
gubitaka u praznom hodu.
Fiksni tečaj konverzije: 1 € = 7,53450 kn
Za sve naše veleprodajne kupce unutar Zagrebačke županije vršimo BESPLATNU DOSTAVU na Vaš kućni prag !!!
iznad 66,36 € (500 Kn) dostava je besplatna na području CIJELE HRVATSKE!
š: x v: x d: x m: kg
Channel Handling
Number of output channels 4 Hi-Z or Lo-Z
(bridgeable per ch. pair) Phoenix PC 5/8-STF1-7,62
Number of input channels
Analog 4 Phoenix MC 1,5/6-ST-3,81
DanteTM/AES67 4 3 x RJ45
Audio
Default gain 32 dB
9K4 12K4 16K4
Input sensitivity 3.0 Vrms 11.8 dBu 3.5 Vrms 13 dBu 3.9 Vrms 14 dBu
Output noise floor (Analog Input) -72 dBV(A) typical
SNR (Analog Input) 113.6 dB(A) 114.8 dB(A) 116 dB(A)
Output noise floor (DanteTM/AES67 Input) -76 dBV(A) typical
SNR (DanteTM/AES67 Input) 117.6 dB(A) 118.8 dB(A) 120 dB(A)
Max input level >+24 dBu
Frequency Response 20 Hz - 20 kHz +0.0 dB/-1.0 dB, @ 8 Ω
Crosstalk <-80dB typical, 20Hz to 1 kHz range
<-60dB @20kHz typical
Input impedance 20 kΩ balanced
THD+N (from 0.1 W to Half Power) < 0.05%
SMPTE IMD (from 0.1 W to Half Power) < 0.01%
Damping factor >2500 20Hz to 500 Hz
DSP
AD converters 24 Bit Tandem™ @ 48 kHz
130 dB(A) Dynamic Range - 0.00005 % THD+N
DA converters 24 Bit Tandem™ @ 48 kHz
132 dB(A) Dynamic Range - 0.00003 % THD+N
Latency 2.6 ms analog Input to amplifier Output
Onboard memory Store and recall up to 50 amplifier snapshot
Delay 2 s (input) + 100 ms (output) for time alignment
Equalizer
Raised-cosine, custom FIR, parametric IIR:
peaking, hi/lo-shelving, all-pass,
band-pass, band-stop, hi/lo-pass
Crossover linear phase (FIR), Butterworth,
Linkwitz-Riley, Bessel: 6 dB/oct to 48 dB/oct (IIR)
Limiters RMS voltage, RMS current, Peak limiter, TruePower™, Dynamic EQ
Damping control Active DampingControl™
Loudspeaker diagnostic Pilot tone monitoring, average impedance monitoring,
load impedance measurement
Startup time <10 s
<0.5 s (with PoE backup power)
Construction
Dimensions 489 x 400 x 44.3 (WxDxH) mm
19.3 x 15.8 x 1.7 (WxDxH) in
Weight 8 Kg (17.6 lb)
IP Class IP 20
Networking
Network 3 x Gigabit Ethernet ports RJ45 connectors
Network modes Switched Mode, Split-Redundant Mode
Remote interface ArmoníaPlus™, Powersoft Cloud
Power supply Universal regulated switch mode with PFC and SRM
Nominal Voltage 100-240 VAC @ 50/60 Hz (400 VAC surge)
Operating Voltage 80-265 VAC @ 50/60 Hz
Supply tolerance +10% -10%
Power system TT/TN
Overvoltage category II
Class of equipment I
AC Mains connector IEC C20 inlet (20 A max)
region-specific power cord provided
Eco Mode consumption 35 W
Standby consumption 20 W Typical, CPU fully functional
PoE Input Class 4 or higher
